Fisher TW82P Digital Line Tracer With Passive Power Detection

Fisher TW-82P with Passive Power Detection.

An active single-frequency and passive power current line tracer that is used to locate and trace buried utilities using conductive, inductive, coupling or passive power tracing methods.

RUGGED CONSTRUCTION

• IP65 Compliant (stands up to water jets)
• Weatherproof
• Impact Resistant

EASY-TO-USE

• Full Time Continuous Readout
• Four-Button Receiver Operation
• Programmable Lateral Mode
• Ergonomic Design – Lightweight

HIGH-PERFORMANCE

• Output Frequency 82.175 kHz
• Ultra-Fast Response
• Powerful Inductive & Conductive Transmitter
• Accurate, Repeatable Readings

RECEIVER SPECIFICATIONS

• Frequency 82.175 kHz
• Standard Mode Automatic response
• Lateral Mode Programmable
• Left/Right Guidance Audible and visual
• Azimuth Indicator Visual
• Over-Target Indicator Visual and audible
• Battery Status Visual
• Signal Strength Indicator Numeric display & audible
• Signal Current Measurement Numeric display, automatic
• Depth Measurement Numeric display, automatic
• Battery Life From 80 to 130 hours depending on the volume setting uses two D-cell batteries (included)
• Weight, with batteries 3.60 lbs (1.6kg)
• Passive Power 50Hz and 60Hz detection. Cathodic Protection detection.

TRANSMITTER SPECIFICATIONS

• Output Frequency 82.175 kHz
• Output Power (nominal) Normal Setting = 0.25 watt High Setting = 1.0 watt
• Conductive Tracing Normal Power: 2 to 8,000 ohms -6dB
• Impedance Matching Range High Power: 2 to 3,000 ohms -6dB
• Inductive Tracing Normal Power: 15 Vm2
• Magnetic Strength High Power: 25 Vm2
• Battery Life approx 130 hours. Uses Four D-cell batteries (included)
• 4 lbs (1.8kg)

Purchase the Fisher TW82P Digital Line Tracer w/PPD and receive FREE shipping To Australia & NZ.
